HIKVİSİON DS-2CE16DOT-EXİPF 1080 P 3,6MM 2MP BULLET KAMERA
Specification
Camera
Image Sensor 2 MP CMOS
Signal System PAL/NTSC
Resolution 1920 (H) × 1080 (V)
Frame Rate
TVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVI: 1080p@25fps/30fps
CVBS: PAL/NTSC
Min. Illumination 0.02 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
Lens 2.8 mm, 3.6 mm Fixed Lens
Field of View 2.8 mm, horizontal FOV: 102°, vertical FOV: 55°, diagonal FOV: 123°
3.6 mm, horizontal FOV: 81°, vertical FOV: 42°, diagonal FOV: 100°
Lens Mount M12
Day & Night ICR
WDR (Wide Dynamic Range) Digital WDR
Angle Adjustment Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Menu
Image Mode STD/HIGH-SAT
AGC Yes
Day/Night Mode Auto/Color/BW (Black and White)
White Balance Auto
AE (Auto Exposure) Mode DWDR, BLC, Global
Noise Reduction 2D DNR
Language English
Function Brightness, Mirror, Smart IR, Sharpness
Interface
Video Output Switchable TVI/AHD/CVI/CVBS
General
Operating Conditions -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
Power Supply 12 VDC ± 25%
Consumption Max. 3.3 W
Protection Level IP66
Material Plastic
IR Range Up to 20 m
Communication HIKVISION-C
Dimension 138.8 mm × 60.9 mm × 57.9 mm (5.465″ × 2.389″ 2.278″)
Weight Approx. 145 g (0.32 lb.)
